Radiant Flooring Panel
生产商:FIRE Instrumentation & Research Equipment Limited,UK





Euroclasses相关产品
  01-SBI (Single Burning Item)
  02-Radiant Flooring Panel
  03-Small Ignition Test Apparatus
  04-Gross Calorific Value
  05-Non-combustibility Test Apparatus
fire02


The Radiant Flooring Panel is the reaction to fire test in the Euroclass system that deals with floor coverings. It measures the spread of flame of the product under thermal exposure from a radiant heat source. It is relevant to classification of a product into classes A2fl, Bfl, Cfl and Dfl. This apparatus can also be used for tests to standards ASTM E648 and DIN 4102; Part 14.

Features

·
Records the Light Attenuation and the Critical Flux at Extinguishment
·
Records stack and chamber temperatures
·
Records radiant panel temperature
·
Stainless steel frame and hood with anodised aluminium panels
·
Contains sliding platform for specimen and an observation window
·
Two high quality stainless steel sample holders and a dummy calibration panel
·
Gas and air flow controlled by high quality Mass Flow Controllers
·
All burners fitted with flash-back protection and electronic flame sensors for enhanced safety

·
Pilot line burner conforming to EN ISO 9239-1
·
Smoke measurement system according to DIN 50055
·
Calibrated pyrometer and total heat flux meter provided
·
Complete operating instructions
·
CE-marked



What is measured

·
Time, in s
·
Mass flow of propane through the burner, in mg.s-1
·
Pressure difference in the general measuring section, in Pa
·
Relative light intensity, dimensionless
·
O2 concentration in VO2 /Vair (%)
·
CO2 concentration in VCO2 /Vair (%)
·
Ambient temperature at air inlet at bottom of trolley, in K
·
Three temperatures in general measurement section, in K
·
Four temperatures just after the hood to measure the temperature rise, in K
